Real-life graphs

Graphs of journeys, costs and filling containers tell a story. Reading them carefully earns easy marks.

Practise this lesson free (6 questions)

More tools

Distance-time graphs

The gradient is the speed. A flat section means stopped. A steeper line means faster.

Velocity-time graphs

The gradient is the acceleration. The area underneath is the distance travelled.

Conversion and cost graphs

A straight line through the origin shows direct proportion, such as converting pounds to euros.
A line that starts above the origin has a fixed charge, such as a taxi that charges £3 plus £2 per mile.
1 2 3 4 5 6 7 8 9 10 5 10 15 20 25 Distance (miles) Cost (£) £17 £3 fixed charge
Taxi fare: £3 fixed charge plus £2 per mile; 7 miles costs £17.
Worked example

A taxi costs £3 plus £2 per mile. What is the cost of a 7-mile journey?

  1. Cost = 3 + 2 × 7
  2. = £17

Answer: £17

Key idea

On distance-time graphs, gradient is speed. On velocity-time graphs, gradient is acceleration and area is distance. A line through the origin shows direct proportion.

Key words
Gradient
The steepness of a line: change in y ÷ change in x. It is m in y = mx + c.
Speed
speed = distance ÷ time
Direct proportion
Two quantities are in direct proportion when one is a constant multiple of the other: y = kx.

All GCSE and International GCSE Mathematics key terms and definitions →

Quick check

Try two quick questions

See if it has sunk in. Answers are marked straight away.

Extra practice

2 more questions

Try each one, then tap to check.

  1. A runner travels 54 km in 3 hours at a steady speed. What is the gradient of her distance-time graph, in km per hour?

    Show the answer

    Answer: 18 km/h

    Gradient = 54 ÷ 3 = 18 km/h.

  2. On a distance-time graph, the line slopes down towards the time axis. What does it show?

    1. Slowing down
    2. Stopped
    3. Going downhill
    4. Moving back towards the starting point
    Show the answer

    Answer: Moving back towards the starting point

    The distance from the start is decreasing, so it is coming back.

Check you have got it

Answer 6 quick questions with instant marking. If you get one wrong, GCSE-ready shows you why and gives you another go. It is free, and you do not need an account.
